Wholesale Ruko Step Drill HSS Spiral Fluted With Split Point No. 12

The CBN ground and spiral flutes guarantee quiet running and high cutting performance. Especially the chip flow is optimized, so even long, non-breaking chips will be removed easily. The optimized chip flow protects the cutting edges and reduces built-up edges and cold weld marks. The cone makes it easier to withdraw the tool from the material.

Main Application:

• Steel 900 N/mm²

• Aluminium

• Brass

• Plastics

Other Application:

• Bronze

• Cast Iron

• Size: 12

• Material: HSS

• Shaft: 3-way clamping surface

• Coating: uncoated

• Shaft Diameter: 10.00 mm

• Size: 12

• Drilling Range: 6.0 - 32.0 mm

• Tolerance: work's specification

• Point Angle: 118°

• Cutting Direction: right hand cutting

• Number of Cutting Edges: 2

• Number of Steps: 12

• Step Angle: 90°

• Length: 76.0 mm

• Net Weight: 0.158kg

• Size no. 12 Drilling range: 6,0 / 9,0 / 12,0 / 16,0 / 20,0 / 22,5 / 25,0 / 28,5 / 32,0 mm
